CAPABILITIES

Whether your need is FDA or industrial products, clear or colored, no slip or high slip, for automated or manual application, Crayex should be your choice in suppliers. More important than the reliable, consistent, satisfaction guaranteed products we offer is the customer first service we provide.

Bags - Flat, centerfold or gusseted Sheeting - Single-wound, double-wound, centerfold, double-fold or J-sheeting Tubing - Flat or gusseted
  • Gauge range from .0008 to .012
  • Flat or centerfold to 125” x 2112”
  • (or 2112” x 125”)
  • Side gusseted to 100” x 56” x 2112”
  • Minimum size of 20” x 20”
  • Gauge range from .0008 to .012
  • Single-wound, double-wound
  • and centerfold to 126” face
  • Double-fold opening to 26’
  • Minimum face width of 5”
  • Gauge range from .0008 to .012
  • Maximum flat face width to 126”
  • Maximum gusseted face width to 100”
  • Minimum flat face width of 20”
  • Maximum roll OD to 40”
Sheets - Single-wound, double-wound or centerfold Sleeves - Flat or gusseted 3-Layer COEX - Sheeting, Tubing
  • Gauge range from .0008 to .012
  • Maximum face width to 126”
  • Minimum face width of 10”
  • Maximum perforated length to 2112”
  • Gauge range from .0008 to .012
  • Maximum flat face width to 126”
  • Maximum gusseted face width to 100”
  • Minimum face width of 20”
  • Maximum perforated length to 2112”
  • Gauge range from .0008 to .010
  • Maximum flat face width to 88”
  • Minimum single – wound width 10”
  • Minimum centerfold width 20”
  • Minimum tubing width 40”
Additional Capabilities

One Color Random Print/Coding 3” and 6” Cores Roll OD’s up to 40”
FDA Approved Products
Venting – random and registered in various forms

Note to all of the above: Minimums and maximums vary with size and gauge.

Film Constructions
Single Wound Sheeting Double Wound Sheeting Centerfold A-Wind Centerfold B-Wind
Layflat Tubing Gusseted Tubing M-Sheeting J-Sheeting

  Center-Slit Sheeting Double Fold Sheeting

Bag Constructions
Centerfold Side Gusseted Bottom Seal Double Pocket - “U”

  Lip Top Gusseted Centerfold

Perforations
Tubular Sleeves Single Wound Sheets Centerfold Sheets Centerfold Sleeves
